150W PSU @ 110V AC Nominal (88 to 127V AC 50/60Hz by selection)

150W PSU @ 230V AC Nominal (190 to 260V AC 50/60Hz by selection)

300W PSU (88 to 260V AC 50/60Hz by selection)

2 Lines x 8 Digit LCD Display

Multi-Color Backlight (Red-Alarm, Yellow-Fault, Blue-Normal)

3 off SPCO Relays 4A Non-Inductive User Configurable

1 off Fault Relay SPCO Relays 4A Non-Inductive

1 off Solid State Beacon Sounder Output

Additional Digital Inputs/Relay Outputs Can Be Added To Highways if Required

Sounder 80dB @ 100mm (Mutable)

2 off RS485 Ports Modbus

Dedicated E-Stop/Slam Switch Input

Dedicated Fire System Interlock

Ethernet Port

USB

Up to 128 off Addressable Series Detectors or I/O Modules Over 4 Addressable Highways

Additional HIghways possible with additional Hub Cards

Note external Booster PSU may be required

-5 to 40 Deg C Full Specification.

To 55 Deg C De-rate PSU by 15%
