Toc-750 Series Power Booster

The Toc-750 series Power Booster is used to supply extra power to long cable runs.

Use With Any IGD 2-Wire Control Panel
LCD Multi-Colour Display Gives Clear Indication of Power Source and Charge Status
Solid State Output Changes State on Switch Over From Mains Power to Battery Power
Volt Free Change Over Relay Changes State on Switch Over From Mains Power to Battery Power (TOC-750-BAT3 only)

Power	110/230V AC 50/60Hz
Construction	ABS
Display	2 Lines x 16 Digit LCD Display Multi-Color Backlight (Red-Alarm, Yellow-Fault, Blue-Normal)
Outputs	1 off SPCO Relays 4A Non-Inductive Both Outputs Change State on Change Over From Mains to Battery
Temperature	-5 to 55 Deg C Full Specification.
Humidity	0-95% RH Non-Condensing
Sealing	IP54
Mounting	Wall Mount
Weight	TOC-750-BAT3 - 6Kg With Batteries Fitted

Main Product

Product Code	Description
TOC-750-BAT3	Toc-750 Power Booster 24V DC O/P 110/230V AC 50/60Hz I/P 150W PSU with 5Ah Batteries
TOC-750-BAT4	Toc-750 Power Booster 24V DC O/P 110/230V AC 50/60Hz I/P 150W PSU

Downloads

Operating Manual
